EURAC M PNEUMATIC CONVEYING VACUUM OR PRESSURE SYSTEMS
DILUTED CONCENTRATION LIGHT PARTICLES
SPECIFICATION OF STANDARD COUPLING
• Outside skin in stainless steel 430
• Black SBR gasket –30°C/+80°C
• Zinc plated bolts
• Conductivity with eyelet
OPTIONS
• All stainless steel 304L version
• White NBR gasket FDA –30°C/+110°C ; European Regulation 1935/2004 CE and REACH 1907/2006 CE
• Silicone VMQ gasket –65°C/+225°C
• Blue silicone gasket –40°C/+180°C
• Viton FPM gasket –20°C/+250°C
• Coupling with clamp and side bars
• Coupling for tubes with different diameters
• Conductivity strip in copper CU A1
• Conductive protecting ring in stainless steel 304L
• Reference to regulation: N°97/23/CE.G2 Art.3 §3
• Example of product marking: D 54
| Ø |
L150 |
||
38,1 |
|||
40 |
|||
45 |
|||
50/50,8 |
|||
54 |
|||
55 |
|||
60/60,3 |
|||
63,5 |
|||
65 |
|||
70 |
|||
75 |
|||
76,1 |
|||
80 |
|||
82 |
|||
84 |
|||
85 |
|||
88,9 |
|||
95 |
|||
100 |
|||
101,6 |
|||
104 |
|||
105 |
|||
108 |
|||
| 114,3 | |||
On stock |
|||
On order |
|||
OPTIONS
• Coupling with clamp and side bars
• Conductive protection ring in stainless steel 304L
• Coupling for two tubes with different diameters
