JET THERM
HIGHT TEMPERATURE ELEVATOR BELT
COATING:
• EPDM black Rubber
• Antistatic
• Coating Th. 3+1 : 3 mm pulley side for a better
adherence and a longer lifetime
• Antiabrasive : ISO 4649< 100 mm3
TEXTILE CARCASS:
• Polyester chain
• Polyamide weft
WORKING TEMPERATURE :
•-20°C to +150°C
APPLICATIONS:
Iron metallurgy, foundry, cement factory, agricultural
and food industry
Suitable for hot products
|
TECHNICAL DATA |
|||||||
RUPTURE STRENGTH (N/MM) |
500 * |
630 |
800 |
1000 * |
1250 * |
1600 * |
|
Number of Plies |
3 |
4 |
4 |
4 |
4 |
4 |
|
Thicknesses * (mm) + Coating |
3+1 |
3+1 |
3+1 |
3+1 |
3+1 |
3+1 |
|
Average weight (kg/m2) |
8,4 |
9,9 |
10,4 |
11,0 |
11,4 |
13,0 |
|
Minimum Roll Diameter (mm) |
315 |
400 |
500 |
630 |
800 |
800 |
|
Minimum Roll Diameter (mm) |
400 |
500 |
630 |
800 |
1000 |
1000 |
|
Width maximum advised (mm) |
500 |
800 |
1000 |
1250 |
1600 |
1600 |
|
|
*Tolerances : Coating Thicknesses +/- 0,2 mm — Total Thickness +/- 1mm — Width +/- 1% — +/- 5 mm minimum |
|||||||
